Tedders TD190
Designed for speed, convenience and reliability, and priced for the budget-conscious operator.
The TD190 teds at 19 ft (5.8 m) and is equipped with four rotors and hydraulic folding for quick, convenient transport. Designed for smooth, gentle handling at maximum ground speeds, even when handling heavy, matted-down w... + Read More
Features
SIX DOUBLE TINES PER BASKET
Six double tines on each basket help to gently pick up a small quantity of forage, flip it and lay it back on the ground without damage or ash. The tender turn of the hay helps quicken dry down time by exposing the crop to sun and air. Decreasing dry down time allows you to get the hay off the field sooner.
TOOLLESS PITCH ADJUSTMENT
The toolless pitch adjustment crank allows you to set proper pitch adjustment, which is crucial to get an accurate flip of the hay. Accurate pitch adjustment minimizes ash content and wear on the machine.
OUTER MOUNTED ROTORS
If you are going to take the time to make another pass in the field and ted, you want to make sure to avoid missing any crop. The outer mounted rotors on the TD190 automatically follow the uneven ground to turn hay, even in low spots.
Specs
| DIMENSIONS AND WEIGHTS | |
| Tedding width | 19 ft |
| Transport Height | 11 ft |
| Transport Width | 10.9 ft |
| Transport Length | 10.4 ft |
| Total Weight | 1225 lbs |
| Tongue Weight | 132 lbs |
| Tire size | 16 x 6.5-8 |
| Basket tilt and adjustment | Manual crank |
| Number of Baskets | 4 |
| Tine Arms per Basket | 6 |
| Type of Tine | Straight tine |
| Torque protection driveline | Radial pin clutch |
| TRACTOR REQUIREMENTS | |
| PTO Horsepower Requirements | 25 hp |
| Hydraulic requirements | 1 single-acting |
| Hydraulic pressure minimum | 1500 psi |
| Hitch | Drawbar clevis connection |
| Drive PTO | 540 rpm |
| FEATURES | |
| SMV Sign | Standard |
