Trailed single-rotor rakes
The 38 T, 42 T and 46 T additions to the Swadro model range were developed in response to farmer demands for a trailed and well-proven single-rotor rake that offers the well-proven Swadro technology. The tandem axle on these models serves also as transport chassis.
Tandem axle: The tandem axle runs on 18" Super Ballon flotation tires. Raking up every stem and offering a crank handle that controls the rake's lateral tilt, the machine ensures effective raking even in heavy crops.
Low power input: It is not pto power that limits the output of a singlerotor rake but the risk of too little load on the tractor's front axle as the machine is being lifted out of work. The answer to this problem is Swadro 38 T, 42 T and 46 T. These trailed models were designed for small and light tractors and applications in sloping fields. They stand out for low tractor power input and are coupled to a rigid drawbar or with a floating drawbar – quick and easy.
Narrow transport width: The side arms on Swadro 46 T fold up easily to provide a compact transport unit and safe travel.
Model | Swadro 42 T |
Work width mm (inch) | 4.200 (13'9") |
Area output approx. ha/h (acres/hr) | 4-4,5 (9.8-11) |
Transport width mm (inch) | 3.400 (11'2") |
No. of tine arms | 13 |
No. of double tines | 52 |
Rotor diameter mm (inch) | 3.300 (10'10") |
Tires | 18/8.5-8/6 PR |
Power requirement approx. kW/hp | 21/31 |
Weight approx. kg (lbs) | 780 (1,720) |
Drawbar | Standard |
Storage length mm (inch) | 4.950 (16'3") |
Storage height mm (inch) | 1.250 (4'1") |
