Professional Brushcutter Machine
Energreen ILF ATHENA is a professional brushcutter machine which, thanks to its innovative technological contents, offers unparalleled performance, great flexibility and operational safety. The machine is equipped with a telescopic boom up to 49 feet, where in addition to the classic... + Read More
Safety and Comfort
– 90° rotating cabin certified FOPS-ROPS
– High visibility panoramic windshield
– Excellent working ergonomics
– Stability Control Device
– Telescoping ballast for the maximum extension
Multifunction
– Several tools available
– Green maintenance
– Aerial pruning and forestry work
– Winter viability
– Front and rear attachment for tools
Quality
– 7’’ LCD display
– Deutz 220 HP powerful engine
– EPA Tier 4f emission
– Main parts made with special steel
– Heavy Duty hydrostatic transmission
Productivity
– 49 ft telescopic boom
– Bidirectional work
– Operation with multiple implements
– Easy and smart to use
– 360° cabin visibility
Visibility is a fundamental element in the correct use of the machines intended for mowing. ILF ATHENA makes this requirement one of its strengths. The large windshield allows the operator to have a valid and total view of his work.
ROTATING CABIN
The cabin is certified in terms of safety by FOPS-ROPS tests against the risk of overturning and falling objects, is adequately soundproofed, equipped with an efficient air conditioning system and equipped with all those requirements necessary to ensure the operator a working environment definitely safe and comfortable. The rotation of the cab allows the mowing of the grass in both DRIVE directions, without the need to turn the machine with a significant reduction in time and labor costs. The rotated cabin allows the operator to maintain a correct body posture, avoiding stress and back or neck problems, as well as managing the work done in great comfort and attention.
3 STYLES IN THE CABIN
The spacious cabin certified FOPS-ROPS is available in three versions, to make your work easier and more comfortable.
MAXIMUM SAFETY AND PROTECTION
The control system (Joystick) is highly automated and includes a series of devices which allow the operator to draft the ground outline and to better focus on the working activity and environment. The hydraulic system is developed in four separated circuits in order to guarantee high handling performances and efficient productivity.
Cabin Technical Data ILF ATHENA | |
Steering wheel | Adjustable |
Joystick | Electronic |
Rotary lamp | Switch in the cabin |
Air conditioning | Electronic |
Rear glasses | Darkened anti UV |
Cabin door | Openable 60 - 40 |
Seat | Air suspension, adjustable |
Power socket for devices | 12 V |
Battery switch | Automatic |
Cabin homologation | FOPS-ROPS |
Machine weight | 39 683,20 lbs |
Engine Technical Data ILF ATHENA | |
Brand | Deutz 6.1 |
Type | 6-Cylinders Diesel |
Power | 220 hp (160 kW) |
Injection | Common Rail DCR |
Emissions | TIER 5f |
Alternator | 12 V - 150 A |
Air engine intake | Pre-heated |
Radiator | Intercooler |
Fan | Reversible, self-cleaning |
Engine data visualization | Onboard computer |
Fuel tank capacity | 79,25 gal |
Hydraulic System Technical Data ILF ATHENA | |
Pump and motors in closed circuit: | |
Cutting head pump | Pistons |
Translation pump | Pistons |
Pump and motors in closed circuit: | |
Arm movement (LS) | Pistons |
Brakes system | Gear |
Steering system | Gear |
Hydraulic distributor | 6 sections |
Hydraulic oil | H46 mineral |
Oil flow | 17,17 - 63,40 gpm |
Oil pressure | 3045,79 - 6961,81 psi |
Flail head weight | 1014,13 lbs 59 055,12 inch model) |
Transmission and Brake System Technical Data ILF ATHENA | |
Transmission | Hydrostatic |
Traction | Permanent all-wheel drive 4x4 |
Speed variation | 0 - 24,85 mph |
Manual gearbox | 2 gears |
Wheel alignment | Electronic control |
Front axle | Oscillating |
Front axle block | Hydraulic |
Steering axles | 2 steering axles |
Axle block | Front 100% |
Rear 100% | |
Parking brake | Negative |
Service brakes | 6 discs |
